Specifications at a Glance

Intended Applications

• - Signs & wayfinding graphics
• - Retail displays & POP
• - Labels & nameplates
• - Two-way marking applications
• - Trade show & event graphics
• - Compatible substrates: Aluminum, Fiberglass, Glass, Rigid plastics, Painted surfaces, Most non-porous
• - Not recommended for vehicles, corrugated, or highly irregular surfaces.

Not recommended for corrugated or highly irregular surfaces, or vehicle applications. For vehicle use, see Gerber High Performance Series 220/225 or 3M™ Controltac™ Film 180.

Physical Properties

• Thickness: 3.0 mil
• Adhesive: Permanent acrylic PSA
• Adhesive Color: Clear
• Adhesive Thickness: 0.8 to 1.0 mil
• Tensile Strength at Break: 3,800 psi
• Elongation: 250%
• Dimensional Stability: <.020 in (.0008 mm)
• Application Temp: 40°F (4°C)
• Operating Temp: -40°F to 200°F (-40°C to 93.3°C)

QUANTUM II has an expected exterior vertical exposure life of up to 5 years.

Key Features

High gloss finish for vivid, eye-catching output — delivers a rich, light-reflective surface that makes colors pop on signs, displays, and retail graphics

Cuts, weeds, and releases cleanly every run — 3.0-mil intermediate plotter-cut vinyl precision-formulated for consistent performance and minimal waste

Certified for GERBER EDGE, EDGE 2, and EDGE FX — genuine Gerber thermal transfer media engineered to work with GerberColor Foils for sharp, reliable print results

Clear permanent PSA — pressure-sensitive adhesive bonds without residue and supports two-way marking applications

Bonds to aluminum, fiberglass, glass, plastics, and most painted surfaces — broad substrate compatibility for sign, label, and display applications

Rated for interior and exterior cut-film use — high gloss finish holds up in demanding environments without fading or lifting

Resources

Quantum II Spec Sheet
