CONVEX Laminate
CONVEX® Laminate – Tough, Durable & Built for Action
As a graphic professional, you need materials that perform as hard as your designs do. CONVEX Laminates delivers the ultimate combination of durability, flexibility, and visual impact—so your graphics can handle every turn, jump, and extreme condition without compromise.
On its own, CONVEX GearWrap™ and CONVEX High-Bond™ base materials are tough and rugged, but add CONVEX Laminate, and you get a protective shield that keeps your graphics bold, vibrant, and long-lasting. Available in 4 or 8 mil thicknesses, these laminates are made for helmets, motocross bikes, ATVs, and other high-impact applications.
Designed for Graphic Professionals – Take your work to the next level with pro-grade materials.
Made for Power Sports & Extreme Applications – Handles speed, dirt, and action effortlessly.
Crystal-Clear Finish – Keeps colors vibrant and sharp, even in the toughest environments.
Push the limits with CONVEX® Big Dog™ Laminate – the 12 mil overlaminate built for extreme performance!
FEATURES & BENEFITS:
- Thick, flexible, rugged; fits smoothly to curved surfaces
- Resists wrinkling
- Resists shrinking: won’t fall off, ooze adhesive, or collect dirt around the edges
- Designed for smooth cutting with any roll-fed or flatbed plotter
|
Printer Type |
Widths (inches) |
Lengths (yards) |
Thicknesses |
Colors |
|
Gerber |
11.5 |
50 |
4 mil |
Clear |
|
Gerber |
13 |
5, 10, 50 |
4 mil |
Clear |
|
Gerber |
13 |
5, 10, 50 |
8 mil |
Clear |
|
Gerber |
13 |
10, 50 |
12 mil |
Clear |
|
Wide Format |
30 |
5, 10, 50 |
4 mil |
Clear |
|
Wide Format |
30 |
5, 10, 50 |
8 mil |
Clear |
|
Wide Format |
30 |
10, 50 |
12 mil |
Clear |
|
Wide Format |
48 |
50 |
4 mil |
Clear |
|
Wide Format |
54 |
50 |
4 mil |
Clear |
|
Wide Format |
54 |
50 |
12 mil |
Clear |
|
Wide Format |
60 |
50 |
4 mil |
Clear |
PHYSICAL PROPERTIES:
Thickness: 4, 8, or 12 mil
Outdoor Life: 2 years
Shelf Life: 2 years stored at 70˚F & 50% RH
Service Temperature Range: -40˚F to 176˚F
Minimum Application Temp.: 50˚F
Adhesive Properties: Clear, permanent acrylic laminating adhesive
CONVEX Laminate Product Sheet
