Pitbull Industrial Polyester - Aggressive Adhesive Label Stock

Locate Id: 2390

Pitbull™ Industrial Polyester Media

UL Recognized. RoHS & REACH Compliant. Mil-Spec Rated. The industrial label film that holds where others fail.

Why Choose Pitbull™ Industrial?
  • ✔ UL Recognized · File MH28890
  • ✔ RoHS Compliant
  • ✔ REACH Compliant
  • ✔ 3TG Compliant
  • ✔ MIL-DTL-43719 Type 1 Class 1
  • ✔ Rated to 302°F
  • ✔ Gerber Punched + Wide Format (up to 60”)

Pitbull™ Industrial Polyester Media brings our customer-favorite Pitbull™ adhesive to our best-selling industrial-grade white polyester(PET) film — and now in wide-format rolls for Latex and UV printers. Engineered for the applications where standard label stocks fail, Pitbull Industrial delivers an extremely aggressive permanent adhesive that bonds to most every surface, including low-energy plastics, powder-coated metal, and other notoriously hard-to-stick surfaces. The dimensionally stable polyester face won’t shrink or stretch, and the lay-flat poly-coated liner punches precisely for clean alignment tabs. UL Recognized (File MH28890), RoHS & REACH compliant, 3TG conflict minerals compliant, and rated to MIL-DTL-43719 Type 1 Class 1 — Pitbull Industrial meets the compliance requirements of industrial, OEM, aerospace, and defense programs. For equipment labeling, nameplates, data plates, asset tags, and high-temperature applications up to 302°F, this is the material that holds.

Features & Benefits

  • - Highly aggressive adhesive ensures labels remain fixed in extreme temperatures
  • - Dimensionally stable; won't shrink or expand
  • - Liner resists moisture and lays flat after printing
  • - Excellent for doming and label alignment tabs
  • - Works with Gerber Edge FX, Gerber Edge II, Gerber Edge I, and wide-format latex and UV printers
  • - Designed for smooth cutting with any roll-fed or flatbed plotter
  • - Works on low-energy surfaces including powder-painted metals and plastics

Physical Properties

  • Thickness: 2 mil polyester + 1.4 mil adhesive
  • Color: White
  • Adhesive: Extremely aggressive pressure-sensitive
  • Liner: Lay-flat poly-coated
  • Dimensional Stability: Won't shrink or stretch
  • Outdoor Life: 2 years
  • Shelf Life: 2 years at 70°F & 50% RH
  • Service Temp: -40°F to 302°F (UL Recognized)
  • Min. Application Temp: 32°F

Compliance & Certifications

Compliance / CertificationStatusReference / File
UL Recognized Component YES File No. MH28890
UL Service Temperature Range Recognized -40°F to 302°F
RoHS Compliant YES EU Directive 2011/65/EU
REACH Compliant YES SVHC Candidate List
3TG Conflict Minerals YES Dodd-Frank §1502— Compliant
Military Specification Qualified MIL-DTL-43719 Type 1 Class 1

Specifications

Thickness 2 mil polyester + 1.4 mil adhesive
Color White
Outdoor Life 2 years
Shelf Life 2 years at 70°F & 50% RH
Service Temp -40°F to 302°F (UL Recognized)
Min. Application Temp 32°F

Roll Sizes

PrinterWidthLengthsThickness
Gerber EDGE 15" 10, 50 yds 2 mil
30" 10, 50yds 2 mil
Wide Format (Latex/UV) Up to 60" 50 yds 2 mil

Custom sizes available. Need a specific roll width for your equipment or workflow? We can accommodate custom widths and lengths — contact us or email orders@graphicms.com with your preferred specifications and we'll get you set up.

Applications

Pitbull™ Industrial Polyester is the material of choice when standard adhesives aren’t enough:

  • - Equipment nameplates and serial identification plates on low-energy plastic housings
  • - Asset tags and data plates on stainless steel, aluminum, and powder-coated surfaces
  • - Industrial control panel labels and UL compliant markings
  • - Aerospace and defense component identification (MIL-DTL-43719 qualified)
  • - High-temperature warning and instruction labels near heat sources
  • - Outdoor equipment and vehicle identification labels (2-year outdoor life)
  • - OEM product labeling programs requiring RoHS/REACH documentation

Peel Strength Test Results

Blind comparison tests on three samples of each product. Values shown in oz/in.

SurfacePitbull™ Industrial PolyesterHigh-Bond™ PolyGerber PermaGrip™Gerber Label Stock
Acrylic 131 110 91 58
Aluminum 101 86 56 61
Glass 133 78 83 59
Polyethylene 82 40 39 12
Polypropylene 91 38 43 10
Powder Paint 100 108 80 44
Stainless Steel 129 60 60 55
Total 767 520 452 299
Shear (hrs) 15 5 30 30
Tack 950 760 873 713

Resources

GMS Media Logo
Pitbull Industrial Product Sheet
Pitbull Industrial Spec Sheet

Pitbull Industrial Polyester: Engineered for Graphic Professionals.

Pitbull™ Industrial Polyester bites into low-energy plastics and doesn’t let go. UL Recognized, RoHS & REACH compliant, Mil-Spec rated. Now in wide-format sizes for Latex and UV printers. Sample it before you spec it.

Request Sample Sample It Today

  1. Pitbull Industrial UL White - 2 mil Polyester - 15 in x 10 yd

    PYPB21510W
    Regular Price $85.84 Special Price $78.75

  2. Pitbull Industrial UL White - 2 mil Polyester - 15 in x 5 yd

    PYPB2155W
    Regular Price $47.21 Special Price $43.31

  3. Pitbull Industrial UL White - 2 mil Polyester - 15 in x 50 yd

    PYPB21550W
    Regular Price $343.35 Special Price $315.00

  4. Pitbull Industrial UL White - 2 mil Polyester - 30 in x 10 yd

    PYPB23010W
    Regular Price $171.68 Special Price $157.50

  5. Pitbull Industrial UL White - 2 mil Polyester - 30 in x 50 yd

    PYPB23050W
    Regular Price $686.70 Special Price $630.00

  6. Pitbull Industrial UL White - 2 mil Polyester - 54 in x 50 yd

    PYPB25450W
    Regular Price $846.86 Special Price $776.94

  7. Pitbull Industrial UL White - 2 mil Polyester - 60 in x 50 yd

    PYPB26050W
    Regular Price $1,373.40 Special Price $1,260.00
